■ Tunnel Size: 500(W) x 300(H) mm   ■ Conveyor Speed: 0.22 m/s   ■ Conveyor Max. Load: 100 kg   ■ Tunnel Size: 500(W) x 300(H) mm   ■ Single Inspection Dosage: <1.35 uGy   ■ Wire Resolution: 40 AWG   ■ Steel Penetration: 10 mm   ■ Film Safety: For ISO 1600   ■ Storage Temperature: -20°C to 60°C   ■ Operating Temperature: 0°C to 45°C   ■ Relative Humidity: 20 to 95% non-condensing   ■ System Power: 220 VAC (+-10%) 50+-3HZ   ■ Power Wastage: 1.0 KW (Max)   ■ Noise < 65DB
